Lockton Door Closer Series 160 - EN 2-4

Product Description
A high-performance rack & pinion door closer adjustable for size 2 to 4 doors — ideal for widths up to 1100 mm and weights to approx. 80 kg. It’s non-handed (works for left or right, inward or outward swing), features adjustable back-check, closing and latching speeds (180°→15°, then 15°→0°). Fire-tested to 4 hours under AS1905 / AS1530 standards and certified to BS EN 1154. Premium construction includes anodised aluminium body, heat-treated steel internals, and built-in pressure relief valve for durability. Comes complete with standard arm, parallel-arm bracket and both timber & self-tapping metal fixings.
(Perfect for residential and light commercial fitments.)

PRODUCT SPECIFICATION

• Rack & Pinion operation
• Suits Left & Right Opening Doors
• Suits Inward & Outward Opening Doors
• Comes with Standard arm
• Parallel Arm Bracket
• Supplied with both Timber and "Self Tapping" Metal Screw Packs
• Adjustable Backcheck (opening limit)
• Simple to read installation instructions
• Can be fitted with optional Hold Open Arm or Sliding Track Arm
• Closing & Latching Speed Adjustment
• Closing range 180° - 15°
• Latching speed range 15° - 0°
• Suitable for door sizes 2-4 adjustable on door with Hex Key
• Size #2: Door width of 850mm & Weight of 40kg
• Size #3: Door width of 950mm & weight of 60kg
• Size #4: Door width of 1100mm & Weight of 80kg
• 10 Year Warranty (*)
• Fire Rated AS1905, As1530 (4 Hours)
• Tested & certified to BS EN 1154:1997
• MADE IN TAIWAN

  4-Hours : This product has been Fire tested & passed up to 4 hours

 Cycle Tested : 500,000 Cycles
